| Model | Capacity (m³/h) | Dimension (m) | Power (kw) | Nozzle Size | Bucket | ||||
|---|---|---|---|---|---|---|---|---|---|
| L | W | H | Inlet | Outlet | Sludge | ||||
| YHLC-1 | 1 | 1.6 | 0.9 | 2.3 | / | DN40 | DN50 | DN80 | 1 |
| YHLC-3 | 3 | 2.2 | 1.2 | 2.3 | / | DN40 | DN50 | DN80 | 1 |
| YHLC-5 | 5 | 2.9 | 1.6 | 2.8 | / | DN40 | DN65 | DN80 | 1 |
| YHLC-II-5 | 5 | 2.2 | 1.2 | 2.3 | 0.55 | DN40 | DN50 | DN80 | 1 |
| YHLC-10 | 10 | 5.2 | 1.8 | 3.1 | / | DN65 | DN100 | DN80 | 1 |
| YHLC-II-10 | 10 | 3.3 | 2.2 | 3.1 | 0.75 | DN65 | DN100 | DN80 | 1 |
| YHLC-20 | 20 | 5.9 | 2.2 | 3.75 | / | DN100 | DN150 | DN100 | 2 |
| YHLC-30 | 30 | 7.5 | 2.2 | 3.75 | / | DN100 | DN150 | DN100 | 3 |
| YHLC-II-30 | 30 | 4.7 | 3.0 | 3.75 | 1.1 | DN100 | DN150 | DN100 | 1 |
| YHLC-50 | 50 | 9.5 | 2.2 | 3.75 | / | DN125 | DN200 | DN100 | 4 |
| YHLC-70 | 70 | 11.5 | 2.2 | 3.75 | / | DN125 | DN200 | DN100 | 5 |
| YHLC-80 | 80 | 10.5 | 3.0 | 3.8 | / | DN150 | DN250 | DN100 | 3 |
| YHLC-100 | 100 | 11.5 | 3.0 | 3.8 | / | DN200 | DN250 | DN100 | 4 |
